BS-2 Socket
The BS-2 is a 2 mm panel-mount banana socket (female connector) designed for secure and reliable electrical connections in low-current test, measurement, and laboratory applications. Rated at 6.3A, 250VAC, it features a nickel-plated brass contact, durable insulated body, and solder termination for excellent electrical performance and long service life. It is widely used in electronic test equipment, educational training kits, laboratory instruments, power supplies, and industrial control panels.
(
No Reviews )
₹ 29.50
Tags bs-2 banana socket
bs-2 socket
bs-2
banana socket
socket
No Cancellation
No Returnable
Product Details
| : |
Add FAQ
| Parameter | Specification |
|---|---|
| Model | BS-2 |
| Product Type | Banana Socket |
| Connector Type | 2 mm Banana Female Socket |
| Current Rating | 6.3 A |
| Voltage Rating | 250 VAC |
| Mounting Style | Panel Mount |
| Mounting Type | Screw Mount |
| Termination Type | Solder Terminal |
| Contact Material | Nickel-Plated Brass |
| Insulation Material | Thermoplastic / ABS |
| Contact Resistance | ≤ 5 mΩ |
| Insulation Resistance | ≥ 100 MΩ @ 500 VDC |
| Dielectric Strength | 500 VAC for 1 Minute |
| Operating Temperature | -20°C to +85°C |
| Available Colors | Black, Red, Green, Blue, Yellow, White |
| Applications | Test & Measurement Equipment, Laboratory Instruments, Educational Kits, Power Supplies, Industrial Electronics, Control Panels |
