EP-42 Chassis Mounting Filter

EP-42 Chassis Mount EMI/RFI Filter is a compact single-stage AC power line filter designed to suppress electromagnetic interference (EMI) and radio frequency interference (RFI) in electronic equipment. Its chassis-mount construction, low leakage current, and high attenuation performance make it ideal for power supplies, photocopiers, medical equipment, food processing machines, printing machinery, and industrial automation systems.

( No Reviews )

₹ 236.00

Order From Whatsapp

Tags EP-42 Chassis Mounting Filter EP-42 EMI Filter EP-42 RFI Filter EP-42 Power Line Filter Chassis Mount EMI Filter Single Stage EMI Filter AC Line EMI Filter AC Power Line Filter Single Phase EMI Filter 120VAC EMI Filter 250VAC EMI Filter 1A EMI Filter 3A EMI Filter 6A EMI Filter 10A EMI Filter 20A EMI Filter Power Supply EMI Filter Medical Equipment EMI Filter Industrial Automation EMI Filter Photocopier EMI Filter Printing Machine EMI Filter Food Processing Machine EMI Filter General Instrumentation EMI Filter EMI Noise Suppression Filter Electromagnetic Interference Filter Radio Frequency Interference Filter Chassis Mounted Power Filter Elcom EP-42 Filter EMI Filter India

No Cancellation

No Returnable

Product Details

Parameter	Specification
Model	EP-42
Product Type	EMI/RFI Power Line Filter
Filter Type	Single Stage EMI Filter
Mounting Type	Chassis Mount
Rated Voltage	120/250 VAC
Frequency	50/60 Hz
Phase	Single Phase
Rated Current	1A, 3A, 6A, 10A & 20A (Model dependent)
Input Connection	6.3 × 0.8 mm Faston Terminal / Solder Type
Output Connection	6.3 × 0.8 mm Faston Terminal / Solder Type
Leakage Current	2 × 0.3 mA
High Voltage Test	2 kVAC for 60 seconds (Line & Neutral to Earth)
Insulation Resistance	≥300 MΩ at 500 VDC
Maximum Voltage Drop	1 V
Operating Temperature	-25°C to +85°C
Housing	Nickel-Plated CRCA Metal Chassis
Function	Suppresses conducted EMI/RFI noise on AC power lines
Features	Compact design, low leakage current, optional MOV surge suppressor, high attenuation
Typical Applications	Power Supplies, Medical Equipment, Photocopiers, Food Processing Machines, Printing Machinery, Industrial Automation Equipment, General Instrumentation
Compliance	CE, CSA & RoHS
