EP-612-20 Chassis Mounting Filter

EP-612-20 Chassis Mount EMI/RFI Filter is a high-performance double-stage single-phase AC power line filter designed to suppress electromagnetic interference (EMI) and radio frequency interference (RFI). Rated at 20A, it delivers high attenuation, low leakage current, and reliable EMC performance, making it ideal for industrial equipment, telecom systems, UPS systems, power supplies, office automation equipment, and medical devices.

( No Reviews )

₹ 236.00

Order From Whatsapp

Tags EP-612-20 EMI Filter EP-612-20 RFI Filter EP-612-20 Power Line Filter EP-612-20 Chassis Mount Filter 20A EMI Filter Double Stage EMI Filter Chassis Mount EMI Filter AC Line EMI Filter AC Power Line Filter Single Phase EMI Filter 120VAC EMI Filter 250VAC EMI Filter Industrial EMI Filter Telecom EMI Filter UPS EMI Filter Power Supply EMI Filter Office Automation EMI Filter Medical Equipment EMI Filter Electrical Panel EMI Filter Conducted EMI Filter EMI Noise Suppression Filter Electromagnetic Interference Filter Radio Frequency Interference Filter Chassis Mounted Power Filter Elcom EP-612-20 Filter EMI Filter India

No Cancellation

No Returnable

Product Details

Parameter	Specification
Model	EP-612-20
Product Type	EMI/RFI Power Line Filter
Filter Type	Double Stage EMI Filter
Mounting Type	Chassis Mount
Rated Voltage	120/250 VAC
Frequency	50/60 Hz
Phase	Single Phase
Rated Current	20 A
Input Connection	Screw Lead Through (M4)
Output Connection	Screw Lead Through (M4)
Leakage Current	2 × 0.3 mA
High Voltage Test	P→E: 1500 VAC, P→N: 1414 VDC
Insulation Resistance	≥300 MΩ @ 500 VDC
Maximum Voltage Drop	1 V Max.
Operating Temperature	-25°C to +85°C
Housing	Nickel-Plated CRCA Metal Chassis
Function	Suppresses conducted EMI/RFI noise on AC power lines
Features	Double-stage filtering, high attenuation, low leakage current, rugged metal enclosure, optional medical and surge suppressor versions
Typical Applications	Industrial Equipment, Telecom Systems, UPS Systems, Power Supplies, Office Automation Equipment, Medical Equipment, Electrical Control Panels
Compliance	EN60939-2:2005, EN60939-3:2015, CE, CSA & RoHS
